Canon imagePROGRAF iPF670 MFP L24 Driver & Software Download

ImagePROGRAF iPF670 MFP L24 Driver

Solution iPF670 L24 MFP is a workflow system that is easy to use, affordable and lightweight in a large format, which makes it easy to scan and copied when a small housing takes up little space.

Efficient design space with a light compact scanner

24 this compact MFP solutions do not require a separate monitor or PC. Printers and scanners for small lightweight integrated into a simple frame only requires little space.

User-friendly – no PC required

MFP solutions designed to simplify all the work process, from document scanning to the end result. The interface is easy to use on a scanner lets you scan and copy without connecting to a PC. You can also navigate easily by changing the various functions and settings. You do the editing by pressing the button on the scanner, such as a panel on the Copier. Everyone could accept it.

Efficiently scan and copy

IPF670 MFP L24 was a versatile imaging solution with the ability to scan and copy in one simple operation. You can also scan directly to a USB stick or perform simple scanning and save the workflow.

Good quality and its accuracy

SingleSensor with multi-LED lighting system generates highly accurate scanning with superior quality. When printing, the Canon of dye inkjet system 5 colors produce a sharp and thin lines with an accuracy of +/-0.1% and the minimum line width 0.02 mm. newly developed magenta Ink also covers a broader spectrum than ever before and presents bright colors on the picture of CAD and GIS, and the text red or high quality photos for posters and POS.

Designed for versatility, practical

This entry level MFP solutions designed to meet the demand for small offices and workgroups to the device simple and easy to use. It is ideal for environments such as the Bureau of design, architects, construction companies, educational institutions and processing companies. The easy operation also makes it very suitable for multifunctional Office projects such as creating posters A2 or A1, heading or subject matter. Supported file formats are PDF, JPEG, TIFF and TIFF-G4. Save the file as a TIFF directly into USB sticks or other formats via a special PC software.

SCANNER TECHNOLOGY

• Scan Technology
• SingleSensor with multiple LED illumination
• Optical Resolution (dpi)600dpi.
• Resolutions for SCAN mode200/400/600dpi
• Resolutions for COPY mode (scan/print)300/300, 300/600, 600/600dpi
• Paper pathFace up, rear exit. Forward document transport only.1 Document return guide included
• Scan width 24"/609.6mm
• Min scan width 6.2"/157.5mm
• Document width 26"/660.4mm
• Max scan length 109"/2768mm
• Weight of scanner 5.36kg (11.8lbs) without Doc return guide
• Dimensions width 935mm
• Dimensions height 131mm
• Dimensions depth With Doc Return Guide - Paper tray folded: 146mm,With Doc Return Guide - Paper Tray flat: 193mm,Without Doc Return Guide - Paper tray folded: 206mm,Without Doc Return Guide - Paper Tray flat: 253mm
• Max & Min Document thickness Designed to scan Canon iPF printer CAD paper.Min = 0.07mm,Max = 0.5mm
• Scan accuracy 0.2% +/-1 pixel
• Power Supply External PSU: Input: 100 - 240V, 50-60Hz,Output: 3.42A at 19V.
• Max Power consumption Standby (sleep): 0.05W,Idle: 10.20W,Scanning: 19.40W
• Compliances Europe: CE mark, Russia: EAC, Other Countries: CB Certification, Energy Star,
• Max scan speed (inches/sec) COPY,300/300dpi Draft = 1ips colour, 3ips mono,300/600dpi Standard = 1ips colour, 3ips mono,600/600dpi Best = 0.5ips colour, 1.5ips mono
• SCAN 200dpi Draft = 1ips colour, 3ips mono,400dpi Standard = 0.5ips colour, 1.5ips mono,600dpi Best = 0.33ips colour, 1ips mono,Scan to USB,USB2, 128 GB FAT32 recommended.
• Scan to Network - L Scan App GB Ethernet. L Scan App - Sets scan directory and file type. Minimum PC specification: • Windows 7/8/10.x - 32bit. • Intel Celeron, Core-Duo, Core-2-Duo or 2.8GHz Hyper-Threading (HT) or AMD Dual-Core processors • 2GB RAM • High speed 7,200rpm Serial ATA (SATA) HDD with minimum 2GB for applications and 20GB free for images. Suggested PC specification: • Windows 7/8/10.x - 64bit. • Intel i3,i5 or i7 processors • 4GB RAM • SATA 6.0Gbit/sec USB3 on the motherboard and SATA 6.0Gbit 7,200 rpm HDD controller.
• Security Unique scanner model is only supported by L Scan App. Scanning cannot be started remotely.
• Modes Scan to USB - RGB/Greyscale/BW, TIFF,Scan to Network - RGB/Greyscale/BW, Tiff, Jpeg, PDF, TiffG4,Copy - RGB/Greyscale/BW,Cloud connectivity is achieved by using Canon’s Direct Print & Share as a separate process. Same for PRINT.
• Control Panel User Interface 3" display (non touch). Home, Left, OK, Right, Start, Stop, Back, Paper Eject buttons. Status LED
• Languages for L Scan App English, French, German, Italian, Spanish, Russian, Portuguese, Czech, Polish
• Environment Temp: 10-35C Humidity: 10-90%
• Acoustic noise 48.4dB gray scan
• Whats in the box? L scanner Printer mounting brackets, fixings & 3mm tool Document return guides (1 for L 24) Calibration target CD for L Scan App software (includes PDF documentation: L Scanner Guide and L Icon Guide per language)L Scanner Guide (includes Assembly Guide, User Guide & Quick Start Guide). Scale factor stickersEthernet cable (2 meter) Power Supply Regional - Mains power cord(s)

PRINTER TECHNOLOGY

• Printer Type 5 Colour - 24"/609.6mm
• Print Technology Canon Bubblejet on Demand 6 colours integrated type (6 chips per print head x 1 print head)
• Number of Nozzles Total: 15,360 MBK: 5,120 nozzles,C, M, Y, BK: 2,560 nozzles each colour
• Print Resolution 2,400 x 1,200 dpi
• Nozzle Pitch 1,200 x 2 includes Non-firing nozzle detection and compensation system
• Guaranteed Minimum Line Width 0.02 mm
• Line Accuracy ±0.1 % or less
• Ink Droplet Size 4 Picoliter per colour
• Ink Capacity Bundled Starter Ink: C,M,Y,Bk, MBk 90ml
• Sales Ink: C,M,Y,Bk, MBK 130ml
• Ink Type Dye/Pigment Reactive Ink
• Dye: Cyan, Magenta, Yellow, Black
• Pigment: 2 x Matte Black
• OS Compatability Windows 32 bit – XP, Vista, 7, 8, 8.1, 10, Server 2003/2003R2, Server 2008
• Windows 64 bit – Vista, 7, 8, 8.1, Server 2003/2003R2, Server 2008/2008R2, Server 2012/2012R2 Mac: OSX – 10.6.8 - 10.10.x
• Printer Languages GARO (Graphic Arts language with Raster Operations), HP-GL/2, HP RTL
• Standard Interfaces USB 2.0 High-Speed,IEEE 802.3 10base-T,IEEE 802.3u 100base-TX/Auto-Negotiation,IEEE 802.3ab 1000base-T/Auto-Negotiation,IEEE 802.3x Full Duplex,IEEE 802.3az EEE

PRINTING - PAGE SIZE/PRINT SPEED

• Printing Speed (A0 Size, Plain Paper)
• 0:28 min (Fast Economy Mode)
• 0:28 min (Fast Mode)
• 0:42 min (Standard Mode)
• Printing Speed (A0 Size, Coated Paper)
• 0:43 min (Fast Mode)
• 1:17 min (Standard Mode)
• 2:05 min (High Quality Mode)

MEMORY

• Standard Memory
• 256MB
• Hard Drive
• N/A

PAPER HANDLING

• Media Width
• Roll paper: 10"/254mm - 24"/609.6mm
• Cut sheet: 8"/203.2mm - 24"/609.6mm
• Media Thickness
• Roll Unit: 0.07 - 0.8mm
• Top Loading Manual Feed: 0.07 - 0.8mm
• Front Loading Manual Feed: 0.5 - 1.5mm
• Minimum Regular Format Size
• Roll: 203.2mm Cut Sheet: 279.4mm
• Maximum Printable Length
• Roll: 18m (varies according to the OS and application) Cut Sheet: 1.6m
• Maximum Media Roll Diameter
• 150.0 mm
• Media Feed and Output
• Roll Feed: One Roll, top loading, front output
• Top Loading Manual Feed: One sheet, front output
• Borderless Printing Width (Roll Only)
• 10" (254 mm), B4 (257 mm), A3 (297 mm), Banner (300 mm), 14" (356 mm), A2 (420 mm), A2+/17" (432 mm), B2 (515 mm), A1 (594 mm), 24" (610 mm)

DIMENSIONS AND WEIGHT

• Physical Dimensions and Weight
• Main Unit: 997 (W) x 698 (D) x 507 (H) mm
• (Excluding consumables and printer stand)
• Main unit with a printer stand and basket open: 997 (W) x 887 (D) x 1,062 (H) mm
• Main Unit with basket in extended position for flatbed stacking: 997 (W) x 1100 (D) x 1062 (H) mm
• Main unit: 46.0 kg
• Main Unit + Printer stand: 56.7 kg
• Software Included
• Canon Printer Driver, Status Monitor/Print Monitor, Printer Driver ExtraKit – Free Layout and iR enlargement Copy, Printer Driver Optimization Module for AutoCAD, Media Configuration Tool, PosterArtist Lite (PC only), Print Plug-in for Microsoft® Office (PC only), Direct Print & Share, Custom Installer Creation Tool

POWER AND OPERATING REQUIREMENTS

• Power Supply
• AC 100 - 240 V (50-60 Hz)
• Power Consumption
• Operation: 140W or less
• Power off Standby: 0.5W or Less
• Sleep mode Power Consumption: 5W or less
• Time to enter sleep mode: Approx. 5 Minutes
• Operating Environment
• 15 - 30°C, 10 - 80 % (Condensation free)
• Accoustic Noise
• Operation: 47 dB approx.
• Standby: 35 dB or less
• Accoustic Power: 6.4 Bels
• Based on ISO 7779
• Regulations
• Europe: CE mark, Germany: TUV, Russia: EAC, Other Countries: CB Certification
• Enviroment Certificates
• ENERGY STAR (WW), RoHS (EU), WEEE (EU), ErP Directive (Lot6, 26), China RoHS, Chemical Substances Regulation, Battery certification (EU, Japan, USA, China, Taiwan), Packing material Regulation（EU, USA, Korea)

WHAT'S INCLUDED

• What's in the Box?
• 1 x print head, 1 x set of starter ink tanks - (C, M, Y, BK, 2 x MBK) 90ml each, 3 inch core adapters, Set up guide, Basic guide, Manual CD-ROM, User software CD-ROM (Mac & Win), Carrying caution leaflet, A2 calibration sheet, Safety/Standard Environment leaflet, Media sample - sheets, PosterArtist Lite leaflet, PosterArtist Lite software CD-ROM, EU/UK Power Cord

OPTIONS

• Optional Items
• Roll Holder Set: RH2-26
• Stand/Basket: ST-27

CONSUMABLES

• User Replaceable Items
• Ink Tank: PFI-107: C, M, Y, BK, 2 x MBK (130 ml)
• Print Head: PF-04
• Maintenance Cartridge: MC-10

NOTES & RECOMMENDATIONS

• Note 1
• Tightly curled documets should be flattened as best as possible and the user should guide the document while it feeds through the scanner to prevent the original re-entering the scanner.
• Note 2
• SCAN to USB & COPY mode scan to internal memory first, then send data to the USB memory stick or the printer. Scan time to USB memory stick will varying depending with individual USB memory sticks.
• Note 3
• SCAN to Network PC - scans directly to the network, so the PC should be of a suitable specification to handle the large amounts of data from large format scans.
• Note 4
• Only 1 copy of the L Scan App should be running on the network subnet with the scanner. It is not possible to select the PC from the scanner.
• Note 5
• Only 1 supported printer should be on the network subnet with the scanner. It is not possible to select the printer from the scanner.

Canon imagePROGRAF iPF670 MFP L24 Operating System Compatibility:

Windows7 / Windows 7 (x64) / Windows 8.1 / Windows 8.1 (x64) / Windows 8 / Windows 8 (x64) / Windows Vista / Windows Vista (x64) / Windows XP / Windows XP (x64) / Macintosh / Mac OS X (10.5/10.6/10.7/10.8/10.9/10.10) / Linux.

Canon imagePROGRAF iPF670 MFP L24 Driver Download - Win, Mac
DOWNLOAD 43.8MB ↔ imagePROGRAF Printer Driver Ver.4.66 (Mac)

DOWNLOAD 43.3MB ↔ iPF670Series imagePROGRAF Printer Driver Version 4.91 for Windows

DOWNLOAD 10.1MB ↔ imagePROGRAF Print Plug-In for Office Ver.1.60 (Windows)

DOWNLOAD 8.9MB ↔ Printer Driver Extra Kit Version 2.30 for Windows

DOWNLOAD 30.8MB ↔ imagePROGRAF Print Plug-In for Office Version 1.50 for Windows

DOWNLOAD 1.2MB ↔ Printer Driver Optimization Module for AutoCAD Version 1.16 for Windows

Driver Download or the Installation for Windows Operating System:

How to install the driver for Canon imagePROGRAF iPF670 MFP L24:

1. First, you need to click the link provided for download, then select the option “Save” or “Save as”. Clicking “Save” is for downloading the file. Meanwhile if you choose “Run” or “Open”, the file downloaded will be automatically installed after the downloading process is completed.
2. For your information, the driver file that you download will be saved in a certain folder that you have set before, especially in the self-extracting form or (.exe format).
3. The last step is double clicking the downloaded file that has the format EXE file for the decompress process. Then, the installation will be automatically started.

How to uninstall the driver by using Control Panel.

Note: The following steps are for Windows 7. The different versions may have the different settings.

1. Come to the Start menu, then you need to choose Control panel --> choose the driver and click “Uninstall a Program.”
2. Wait until a page is appear with the list of the installed program. Then you need to double click the program that you want to uninstall.
3. At last, choose “Yes” and “Ok”. The uninstall process is completed.

Driver Download or Installation process for Mac Operating System:

How to install driver of Canon imagePROGRAF iPF670 MFP L24 in Mac:

1. First, you need the file of the driver. When you have already completed the downloading process, it will be saved in the certain folder. You can see it at the computer settings.
2. Second, you need to double click the downloaded driver file and mount it on the Disk Image.
3. The third step is that you need to double click again the mounted Disk Image.
4. At last, double clicking the packaged driver file. Do not worry, the installation is about to be started automatically.

However, the step-by-step of the installation (and vice versa), it can be differed depend upon the platform or device that you use for the installation of Canon imagePROGRAF iPF670 MFP L24.The above mentioned, the installation is occurred using Windows 7 and Mac for windows XP or windows 8 is not much different way.
